Overall Length : 13780 mm

Overall Width : 2,500 mm

Overall Height : 3,995.00 mm

Landing Leg Setting : 2,500 mm

Wheelspan : 8,580+1310 mm

Axle Spacing : 1,310 mm

King Pin Setting : 1250mm

King Pin Plate Height: 1480mm

TANK:

Loading Capacity : 70T

Compartment: 2

Tank shell : Q345 5mm

Dished ends : Q345,5mm thickness

Pipe material : Carbon steel

Discharging Hose Diameter : 4”

Discharging valve 4” butterfly valve

Discharging Hose Length : 7,000 mm

Hose quick coupling : 4” female quick coupling.

Discharging capacity : ≥1m3/min

Working pressure : 0.2 Mpa

Test pressure : 0.3 Mpa

Manhole : THREE

MAX. Horizontal Discharging Distance: 5,000 mm

MAX. Vertical Discharging Distance : 15,000 mm

RUNNING GEAR:

Suspension : Undermount tri-axle suspension with equalizer;

10-Leaf Spring.

Axle : (FUWA 13T capacity)

Brake : Dual line pneumatic brake system.

Parking Brake : Type 30/30 spring brake system on two axles.

Wheel : 8.0-20,10 holes steel Disc wheel, 12Pcs.

Tire : 11.00R20 STEEL RADIUS TYRE, 12 Pcs

King Pin : 3.5” Botls type

LANDING LEG: Two speed manual operation type with sand shoe.
