Product Details
- Size: 50cbm
- Place of Origin: Shandong
- Brand Name: CIMC Dongyue
- Model Number: Container chassis
- Weight: 6500.000 kg
| Tare Weight | About 7.0T |
| Dimension | 12500mm*2490mm*1560mm |
| Loading Capacity (T) | ≤ 40 T |
| Axle | 2 axles, 13 T FUWA Brand |
| Rim | 8.00-20 |
| Tire | 1100R20 Triangle Brand 8pieces |
| Suspension | Mechanical suspension (America Type) |
| Spring leaf | 90(W)mm*13(Thickness)mm*10 Layer |
| King pin | JOST brand 3.5inch bolts type |
| Support leg | JOST C200 (Double speed) |
| Main beam | Height: 500mm, upper plate is 14mm, middle plate is 8mm, Down plate is 16mm; Material is Q345B Steel. |
| Side wall | Height is 800mm, you can choose freely. |
| Brake chamber | WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber(TKL brand); One piece of 45L air tanks |
| ABS | Without |
| Twist Locks | 12 pieces |
| Valve | WABCO valve |
| Light | LED light |
| Voltage | 24V |
| Receptacle | 7 ways (7 wire harness) |
| Tool box | One piece, 1m×0.5m×0.5m (Size can be choose freely)(equipped with 1 unit Tire spanner,1 unit gudgeon sleeve and 1 unit cranking bar) |
| Painting | Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint |
| Shipping Terms: | By bulk cargo carrier, RORO or 40HQ container. |
