- Size: 50cbm
- Place of Origin: Shandong
- Brand Name: CIMC Dongyue
- Model Number: Terminal Container Semi Trailer
- Weight: 8000.000 kg
Specification | |
Type | CIMC manufacture terminal straight frame trailer |
Function | 1*20/2*20/1*40 container shultting within container terminal |
Overall dimension | 12,620*2,720*1,850mm |
Rear tractor clearance radius | 2,130mm |
Tare weight | 9,000kg |
Payload | 65ton |
Main beam | Beam height: 500mm Upper plate: 16mm Middle plate: 10mm Down plate: 18mm |
Side beam | 16# U shaped steel |
Front and rear guide plate | Length 1850mm |
Side guide plate | Length 500mm |
Landing leg | Jost A400 |
Suspension | Germany suspension |
Leaf spring | Thicken 90 width, 8 pcs |
Axle | Fuwa, 3*13T |
Tire | Boto brand, 13R22.5, 13pcs |
Rim | 9.75, 13pcs |
Brake Val | WABCO |
Brake Chamber | 4 Double, 2 Single |
Spare Tire Carrier | 1 pcs |
Tool box | None |
Electrical system | 24V Receptacle: 7 way Light type: LED |
Colour and marking | Comply with the customer’s request. |
